Bay-o-net Assembly is the brief element of oil-transformer, to protect the equipment when over-current. When install the fuse wire in it, the Bay-o-net will provide the safe, highly efficient protection, according to the current, oil temperature.
The Bay-o-net Assembly is suitable for current sensing fuse wire, dual sensing fuse wire, dual element fuse wire, and ELSP current-limiting backup fuse,etc.
It is suitable for high-voltage power system with alternating current of 50HZ, standard voltage of 15.5kv, current rating of 140A. It must be combining with Magn X Interrupter of ELSP Current-limiting Backup Fuse to protect transformer from overload and short circuit.
Abroad series model numbers :
4038108C09B
4000353C08M
4038108C04M
4000353C10M
4000353C04M
4000358C12M
124080-5
4000358C14M
4038108C05B
4038108C03B
4000358C03B
4000353C12M
4000353C16M
4000353C14M
4038108C12M
4000353C17M
124080-12
4038108C14m
124080-8
124080-6
124080-15
4038108C06B
4000353C14M
124080-25
4038361C03M
124080-35
4038108C11B
124080-30
Model and meaning
Electrical Rating:
| Description | Parameters |
| Impulse withstand voltage | 150kV |
| AC withstand voltage, 1min | 50kV |
| Voltage | Maximum Single-Phase Interrupting Rating | Voltage | Thermal circuit |
| 8.3kV | 3000A/3500A | 10.0kV | 160A |
| 15.5kV | 2500A/2500A | 15.5kV | 150A |
| 23kV | 1000A/1000A | 26.7kV | 80A |
